Honda NX500

Specifications

• Power & Performance

  • Displacement
    471 cc
  • Max Power
    46.9 bhp @ 8600 rpm
  • Max Torque
    43 Nm @ 6500 rpm
  • Top Speed
    -

  • Mileage - Owner Reported
    26.5 kmpl
  • Transmission
    6 Speed Manual
  • Transmission Type
    Chain Drive
  • Gear Shifting Pattern
    1 Down 5 Up
  • Clutch
    E-Clutch
  • Riding Range
    463.8 km
  • Riding Modes
    -
  • Engine Type
    2 Cylinder, Liquid Cooled
  • Bore x Stroke
    67 mm x 66.8 mm
  • Compression Ratio
    10.7:1
  • Spark Plugs
    1 Per Cylinder
  • Battery
    12V, 7.4Ah
  • Emission Standard
    BS6 Phase 2
  • Fuel Type
    Petrol

  View More(+14)

  Was this helpful?

  ---

• Brakes & Wheels

  • Braking System
    Dual Channel ABS
  • Front Brake
    Disc, 296 mm, 4 piston caliper
  • Rear Brake
    Disc, 240 mm, 1 piston caliper
  • Wheel Type
    Alloy

  • Wheel Size
    Front - 19 inch, Rear - 17 inch
  • Tyre Size
    Front - 110/80 - R19, Rear - 160/60 - R17
  • Tyre Type
    Tubeless
  • Tyre Pressure (Rider Only)
    Front - 29 psi, Rear - 36 psi
  • Tyre Pressure (Rider & Pillion)
    Front - 29 psi, Rear - 36 psi

  View More(+5)

  Was this helpful?

  ---

• Suspensions & Chassis

  • Front Suspension
    Showa 41mm SFF-BP upside-down (USD) front forks
  • Rear Suspension
    Pro-Link mono-suspension
  • Front Suspension Preload Adjuster
    No
  • Rear Suspension Preload Adjuster
    Yes

  • Chassis Type
    Steel Diamond

  View More(+1)

  Was this helpful?

  ---

• Dimensions

  • Additional Features
    -
  • Kerb Weight
    196 kg
  • Seat Height
    830 mm
  • Seat Length
    -

  • Ground Clearance
    181 mm
  • Fuel Tank Capacity
    17.5 litres
  • Reserve Fuel Capacity
    2.6 litres
  • Overall Dimensions (LxWxH)
    2165 mm x 829 mm x 1413 mm
  • Wheelbase
    1447 mm

  View More(+5)

  Was this helpful?

  ---

• Warranty and Services

  • Vehicle Warranty
    -
  • No. of Free Services
    0
  • 1st Service
    -
  • 2nd Service
    -

  • 3rd Service
    -
  • 4th Service
    -
  • 5th Service
    -

  View More(+3)

  Was this helpful?

  ---

•

  Report incorrect specifications

• Instrument Cluster

  • Instrument Console
    5 " TFT Display with Brightness Control
  • Mobile Phone Connectivity
    Bluetooth
  • GPS & Navigation
    Turn by Turn Navigation
  • Average Fuel Consumption
    -

  • Real Time Mileage Indicator
    -
  • Speedometer
    Digital
  • Odometer
    Digital
  • Fuel Gauge
    Digital
  • Distance to Empty
    -
  • Voice Assist
    -
  • Tripmeter
    2 Tripmeters, Digital
  • Tachometer
    Digital
  • Stand Alarm
    Yes
  • Gear Indicator
    Yes
  • Gear Shift Light
    Yes
  • Low Battery Indicator
    -
  • Low Fuel Indicator
    Yes
  • Low Oil Indicator
    -
  • Service Reminder Indicator
    -
  • Hazard Warning Indicator
    -
  • High Beam Indicator
    Yes
  • Engine Temperature Indicator
    -
  • Malfunction Indicator
    Yes
  • Average Speed
    -
  • OTA Updates
    Not Available
  • Call/SMS Alerts
    Yes
  • Clock
    Yes
  • Additional Features
    -

  View More(+24)

  Was this helpful?

  ---

• Safety & Convenience

  • Saree Guard
    Yes
  • Quickshifter
    No
  • Traction Control
    Yes
  • Cruise Control
    -

  • USB Charging Port
    -
  • Side Stand Engine/Motor Cut-off
    Yes
  • Keyless Lock/Unlock
    No
  • Start Type
    Self Start
  • Silencer Cover
    Yes
  • Kill Switch
    Yes
  • Automatic Start Stop
    No
  • Ride by Wire
    -
  • Tyre Pressure Monitoring System
    -
  • Silent Start
    No
  • Additional Features
    -
  • Heated Grip
    -
  • Adjustable levers
    -
  • Windscreen
    -
  • Center stand availability
    -

  View More(+15)

  Was this helpful?

  ---

• Mobile App Monitoring

  • Vehicle Location Tracking
    No
  • Geo Fencing
    No
  • Additional Features
    -
  Was this helpful?

  ---

• Lights

  • Headlight
    LED Headlamp
  • DRLs (Daytime Running Lights)
    Yes
  • Brake/Tail Light
    LED
  • Hazard Warning Lights
    -

  • Pass Light
    Yes
  • Turn Signal
    LED
  • Additional Features
    Emergency Stop Signal

  View More(+3)

  Was this helpful?

  ---

• Seat & Storage

  • Under Seat Storage
    No
  • Pillion Seat
    Yes
  • Pillion Comfort
    Footrest, Grab rail
  • Additional Features
    -
  Was this helpful?

  ---

•

  Report incorrect features
